Tire Retread Overhead Conveyor System and Components

1st Source Products offers Overhead Conveyor Systems and Components to the Tire Retread Industry at very competitive pricing.

Installation available.
Four Wheel Trolley

Standard Four Wheel Trolley

Part No. E-20-440

$53.50



Each



Buy Now

The Four Wheel Carrier has a solid 3/8" (9.525 mm) thick body with four machined 2-1/8" (53.975mm) diameter wheels. The welded eyebolt at the bottom has a 1"(25.4mm) inside diameter for hanging products. The carrier is zinc plated and has a load capacity of 250 lbs (113.5 kg). The Four Wheel Carrier is used in manual enclosed track conveyor systems, tire retread systems, heavy-duty tool rails and in custom applications. Note: Tire Retread 'J' Hooks are sold separately.

Solid Steel J Hook

Solid Steel J Hook

Part No. E-20-440-J-W

$45.00



Each



Buy Now

This Retread J-Hook is formed from hot rolled steel. It is 1" (25.4 mm) in diameter, and features a 45 degree chamfer at both ends of the hook. 250 lbs (113.4 kg) capacity.

Conveyor Straight Track

Conveyor Straight Track

Part No. E-10-110A

$70.00



One 10 Ft. Section



Buy Now

This rugged 3/16" (4.76 mm) thick high strength steel tubular track is provided in 10' (3.05 m)sections and comes standard with a professional powder-coated finish.

Weight is 50 lbs (22.7 kg) per 10' (3.05 m) section. Load capacity is up to 1,000 lbs (454 kg) if the track is supported on 5' (1.525 m) centers. In addition to hand-pushed and powered E-Trac applications, it is also used in various power and free systems including tool rails, tire retread systems, sliding door and gate applications, etc.

Overall Dimensions: 2-11/16"(68.262 mm) tall x 2-1/8" (53.975 mm) wide x 10' (3.05 m) long

Four Wheel Trolley

Four Wheel Hook Carrier

Part No. E-20-330

$33.75



Each



Buy Now

This Four Wheel Hook Carrier body has a two piece solid steel plate construction with four 2 1nd 1/8 inches diameter machined wheels and Full Ball Comp bearings. The welded eye bolt is designed to interface with the Tubular J-Hook. The load capacity for this carrier is 250 lbs.

J Hook

Tubular J Hook

Part No. E-20-330-J

$19.50



Each



Buy Now

This Tubular J-Hook is designed to interface with the Four Wheel Hook Carrier. The tube is 1 and 1/4 inches diameter steel and has a wall thickness of 0.12 inch. The load capacity of this Tubular J-Hook is 250 lbs.

Conveyor Track Curve

Conveyor Track Curve

Part No. E-14-1890A

- 18" Radius Horizontal 90 Degree Curve


$133.50



Each



Buy Now

Part No. E-14-2490A

- 24" Radius Horizontal 90 Degree Curve



$133.50



Each



Buy Now

These curves are used in non-powered hand pushed E-Trac enclosed track conveyor system applications. They are constructed of 3/16" (4.76 mm) thick high-strength steel channels stitch-welded together, and features a professional powder-coated finish.

Support Bracket

Support Bracket

Part No. E-10-200

$11.00



Each



Buy Now

The Support Bracket is used to suspend the conveyor track using 1/2"(12.70 mm) diameter drop rod hangers. It is a tubular piece formed out of 1/4"(6.35 mm) thick high-strength steel. It has a load capacity of 1,000 lbs (454 kg). It features a professional powder-coated finish. This bracket should be used when the track joints are welded. Typically, these are used on 10' (3.05 m) centers and at every tangent point in the system. The support bracket slides over the straight track and can be welded in position.

Welding Jig

Welding Jig

Part No. E-10-230

$70.00



Each



Buy Now

The Track Welding Fixture is used to align and hold track sections together to facilitate welding of the joint. It is constructed of brass components and has a 5/8" (15.875 mm) adjustable bolt that allows for tightening or loosening the fixture. Once loosened, it can be slid to the next track joint.

Support Bracket

Joint Bracket

Part No. E-10-210

$45.00



Each



Buy Now

The Joint Bracket is used to suspend the conveyor track using 1/2" (12.7 mm) diameter drop rod hangers. It is tubular 1/4" (6.35 mm) thick high-strength steel, with a powder-coated finish. It has a 9/16" (14.288 mm) hole in the top to allow clearance for the drop rod. This bracket is normally used when the track joints are not welded. These are only used at track joints. For intermediate track support, we recommend using E-10-200 Support Brackets. The Joint Bracket has a load capacity of 1,000 lbs (454 kg).

Carrier Insert Section

Carrier Insert Section

Part No. E-10-250

$166.75



Each



Buy Now

This 24"(609.6mm) long section is formed of 3/16"(4.76mm) high strength steel, and is used on every hand pushed conveyor system to facilitate inserting carriers into the conveyor track. It features a professional powder-coated finish. It can also be used in powered conveyor systems to install chain. It should be located in an easily accessible location in the conveyor system. It has a hinged side. The Carrier Insert Section should never be opened while the conveyor is in operation.

Left Hand Standard Two Way Frog Switch

Left Hand Standard Two Way Frog Switch

Part No. E-21-110

$750.00



Each



Buy Now

The Left Hand Standard 2-Way Frog Switch is used in manual, hand-pushed systems where it is necessary to switch between two different tracks. 1,000 lbs (453.6 kg) capacity. It is shipped as a complete unit less the throw-control. The overall frame size is 18-1/4" (463.55 mm) x 14-1/4" (361.95 mm). The frame comes with (4) 9/16" (14.29 mm) diameter holes for mounting purposes. Both the framework and frog plate are constructed of high strength carbon steel and then covered with a durable powder coated finish.

Left Hand Standard Universal Frog Switch

Left Hand Standard Universal Frog Switch

Part No. E-21-130

$675.00



Each



Buy Now

The Left Hand Standard Universal Frog Switch is used in manual hand-pushed systems where it is necessary to switch between tracks. 1,000 lbs (453.6 kg) capacity. It is shipped as a complete unit less the throw-control. The overall frame size is 16" (406.4 mm) x 16-1/4" (412.75 mm). The frame comes with (4) 9/16" (14.29 mm) diameter holes for mounting purposes. Both the framework and frog plate are constructed of high strength carbon steel and then covered with a durable powder coated finish.

Right Hand Standard Two Way Frog Switch

Right Hand Standard Two Way Frog Switch

Part No. E-21-210

$750.00



Each



Buy Now

The Right Hand Standard 2-Way Frog Switch is used in manual, hand-pushed systems where it is necessary to switch between two different tracks. 1,000 lbs (453.6 kg) capacity. It is shipped as a complete unit less the throw-control. The overall frame size is 18-1/4" (463.55 mm) x 14-1/4" (361.95 mm). The frame comes with (4) 9/16" (14.29 mm) diameter holes for mounting purposes. Both the framework and frog plate are constructed of high strength carbon steel and then covered with a durable powder coated finish.

Right Hand Standard Universal Frog Switch

Right Hand Standard Universal Frog Switch

Part No. E-21-230

$675.00



Each



Buy Now

The Right Hand Standard Universal Frog Switch is used in manual hand-pushed systems where it is necessary to switch between tracks. 1,000 lbs (453.6 kg) capacity. It is shipped as a complete unit less the throw-control. The overall frame size is 16" (406.4 mm) x 16-1/4" (412.75 mm). The frame comes with (4) 9/16" (14.29 mm) diameter holes for mounting purposes. Both the framework and frog plate are constructed of high strength carbon steel and then covered with a durable powder coated finish.

Three Way T Switch

Three Way T Switch

Part No. E-21-400

$950.00



Each



Buy Now

The 3-Way 'T' Switch is used in manual E-Trac systems where it is necessary for one line to tee directly into another line. This switch allows the carrier to then be pushed either way. This switch is used primarily in tire retread applications.

The 3-Way 'T' Switch is shipped as a complete unit and has a short manual chain throw in the center on the bottom of the switch. The overall size is approximately 24" (609.6 mm) x 16" (406.4 mm). Load capacity is 1000 lbs (453.6 kg).


Manual Throw Control for the Standard Frog Switch

Manual Throw Control for the Standard Frog Switch

Part No. E-21-510

$410.00



Each



Buy Now

The Manual Throw Control allows the overhead conveyor operator to control the carrier in a manual-type system. This model is for use with the Standard Frog Switch. The Manual Throw Control adds 1-1/4" (31.75 mm) of height to the Frog Switch. Extension arms are not provided since each possible application is different. The are typically constructed of high-strength carbon steel angle and sheet.

Manual Throw Control for the Universal Frog Switch

Manual Throw Control for the Universal Frog Switch

Part No. E-21-530

$410.00



Each



Buy Now

The Manual Throw Control allows the overhead conveyor operator to control the carrier in a manual-type system. This model is for use with the Universal Frog Switch. The Manual Throw Control adds 1-1/4" (31.75 mm) of height to the Frog Switch. Extension arms are not provided since each possible application is different. The are typically constructed of high-strength carbon steel angle and sheet.

Two Wheel Carrier 1/2 inch diameter shank

Two Wheel Carrier 1/2 inch diameter shank

Part No. E-20-220

$45.00



Each



Buy Now

The Two Wheel Carrier with 1/2" (12.70 mm) shank has a drop-forged body with a zinc plated finish. Wheels are 2-1/8" (53.975 mm) in diameter. Capacity is 125 lbs (56.75 kg). It is used in manual, power and free conveyor systems, on tool rails, for sliding doors and gates and in various custom applications. The nut and cotter pin are not included.

Two Wheel Carrier 5/8 inch diameter shank

Two Wheel Carrier 5/8 inch diameter shank

Part No. E-20-210

$45.00



Each



Buy Now

The Two Wheel Carrier with a 5/8" (15.875 mm) shank has a drop-forged body with a zinc plated finish. Wheels are 2-1/8" (53.975 mm) in diameter. Capacity is 125 lbs (56.75 kg). It is used in manual, power and free conveyor systems, on tool rails, for sliding doors and gates and in various custom applications. The nut and cotter pin are not included.

Wide Base J-Hook

Wide Base J-Hook

Part No. E-20-440-J-WB

$90.00

Buy Now

This Retread J Hook is formed from hot rolled steel. It is 1 inch in diameter and features a 45 degree chamfer at both ends of the hook. The vertical useable length is 14 inches, and the horizontal useable length is 16 and 1/4 inches. The load capacity of this hook is 250 lbs.


Request our hard copy brochures to be mailed to you free of charge here.
